Version 7.0 45 Mediant 3000
User's Manual 3. Default OAMP IP Address
3 Default OAMP IP Address
The device is shipped with a factory default IP address for operations, administration,
maintenance, and provisioning (OAMP), through its VoIP LAN interface. You can use this
address to initially access the device from any of its management tools (embedded Web
server, EMS, or Telnet/SSH). You can also access the device through the console CLI, by
connecting the device's serial (RS-232) port to a PC.
The table below lists the device's default IP address.
Table 3-1: Default VoIP LAN IP Address for OAMP
IP Address Value
Application Type OAMP + Media + Control
Private IP Address
 TP-6310 or TP-8410 blade in Slot 1: 10.1.10.10
 TP-6310 or TP-8410 blade in Slot 3: 10.1.10.11 (only for HA
mode)
Prefix Length 255.255.0.0 (16)
Default Gateway 0.0.0.0
VLAN ID 1
Interface Name OAM
