Version 7.0 163 Mediant 3000
User's Manual 13. Network
Parameter Description
Port (1-3)
[Srv2Ip_Port1/2/3]
Defines the TCP or UDP port on which the service is to be found.
By default, no value is defined.
13.8 Configuring NFS Settings
Network File System (NFS) enables the device to access a remote server's shared files
and directories and to handle them as if they're located locally. The device can use NFS to
load cmp, ini, and Auxiliary files through the Automatic Update mechanism (see
Configuration using FTP or NFS).
You can configure up to 16 different NFS file systems. As a file system, the NFS is
independent of machine types, operating systems and network architectures. Note that an
NFS file server can share multiple file systems. There must be a separate row for each
remote file system shared by the NFS file server that needs to be accessed by the device.
The following procedure describes how to configure NFS through the Web interface. You
can also configure it through ini file (NFSServers).
 To configure an NFS file systems:
1. Open the Application Settings page (Configuration tab > System menu >
Application Settings).
2. Under the NFS Settings group, click the NFS Table button; the NFS table
appears.
3. Click Add; the following dialog box appears:
Figure 13-7: NFS Table - Add Row Dialog Box
4. Configure an NFS according to the parameters described in the table below.
5. Click Add, and then save ("burn") your settings to flash memory. The remote NFS file
system is immediately applied, which can be verified by the appearance of the "NFS
mount was successful" message in the Syslog server.
