User's Manual 72 Document #: LTRT-89730
Mediant 3000
Button Name
Up
Moves a selected row one index up. The index number of the row
changes according to its new position in the table. The row that
previously occupied the index row and all rows below it are moved
one index down in the table.
Notes:
The button is available only if the table contains more than one
row and is sorted according to 'Index' column; otherwise, the
button is grayed out. For sorting tables, see ''Sorting Tables by
Column'' on page 73.
The button appears only in certain tables.
Clone
Adds a new row with identical settings as the selected row.
Note: The button only appears in certain tables.
7.1.7.2 Toggling Display Mode of Table Dialog Boxes
Add and Edit dialog boxes that appear when you click the Add and Edit buttons
respectively, by default display parameters in Tab view, whereby parameters are grouped
under tabs according to functionality (e.g., Rule, Action, and Status). You can change the
view mode to Classic view, whereby all parameters appear in one list and whereby
parameters are separated according to functionality by a heading instead of a tab.
To toggle between Tab and Classic view:
Click the Classic View or Tabs View link located at the bottom of the dialog box.
7.1.7.3 Scrolling through Table Pages
You can define the maximum number of rows (indices) to display in the table. To view
additional rows, you can scroll through the table pages. The figure below shows the table
page navigation area, which is located below the table:
Figure 7-11: Viewing Table Rows per Page
Table 7-5: Row Display and Page Navigation
Item # Description
1
Defines the page that you want to view. Enter the required page number or use the
following page navigation buttons:
- Displays the next page
- Displays the last page
- Displays the previous page
- Displays the first page
2
Defines the number of rows to display per page. You can select 5, 10 (default), or 20.
3
Displays the currently displayed number of rows out of the maximum configured.
