Version 7.0 111 Mediant 3000
User's Manual 9. SNMP-Based Management
Parameter Description
Trap User
[SNMPManagerTrapUser]
Associates a trap user with the trap destination. This determines the
trap format, authentication level, and encryption level.
 v2cParams (default) = SNMPv2 user community string
 SNMPv3 user configured in ''Configuring SNMP V3 Users'' on page
112
Trap Enable
[SNMPManagerTrapSendi
ngEnable_x]
Activates the sending of traps to the SNMP Manager.
 [0] Disable

Enable (Default)
9.4 Configuring SNMP Trusted Managers
The SNMP Trusted Managers table lets you configure up to five SNMP Trusted Managers
based on IP addresses. By default, the SNMP agent accepts SNMP Get and Set requests
from any IP address as long as the correct community string is used in the request.
Security can be enhanced by using Trusted Managers, which is an IP address from which
the SNMP agent accepts and processes SNMP requests.
The following procedure describes how to configure SNMP trusted managers through the
Web interface. You can also configure it through ini file (SNMPTrustedMgr_x).
 To configure SNMP Trusted Managers:
1. Open the SNMP Trusted Managers table (Configuration tab > System menu >
Management > SNMP > SNMP Trusted Managers).
Figure 9-3: SNMP Trusted Managers Table
2. Select the check box corresponding to the SNMP Trusted Manager that you want to
enable and for whom you want to define an IP address.
3. Define an IP address in dotted-decimal notation.
4. Click Submit, and then save ("burn") your settings to flash memory.
