User's Manual 864 Document #: LTRT-89730
Mediant 3000
Parameter Description
Gateway Calls on page 772.
SBC CDR Format Table
SBC CDR Format Table
configure voip >
services cdr > cdr-
format sbc-cdr-format
[SBCCDRFormat]
The table defines CDR customization rules for SBC calls.
The format of the ini file table parameter is:
[ SBCCDRFormat ]
FORMAT SBCCDRFormat_Index = SBCCDRFormat_CDRType,
SBCCDRFormat_ColumnType, SBCCDRFormat_Title,
SBCCDRFormat_RadiusType, SBCCDRFormat_RadiusID;
[ \SBCCDRFormat ]
For a detailed description of the table, see Customizing CDRs for
SBC Calls on page 775.
58.3.4 Heartbeat Packet Parameters
The Heartbeat packet parameters are described in the table below. The device sends a
heartbeat packet to ensure that the far-end is passing traffic.
Table 58-21: Heartbeat Packet Parameters
Parameter Description
[HeartBeatDestIP]
Defines the destination IP address (in dotted format notation) to which
the device sends proprietary UDP 'ping' packets.
The default IP address is 0.0.0.0.
Note: For the parameter to take effect, a device reset is required.
[HeartBeatDestPort]
Defines the destination UDP port to which the heartbeat packets are
sent.
The range is 0 to 64000. The default is 0.
Note: For the parameter to take effect, a device reset is required.
[HeartBeatIntervalmsec]
Defines the delay (in msec) between consecutive heartbeat packets.
 [10] = 100000
 [-1] = (Default) disabled
Note: For the parameter to take effect, a device reset is required.
58.3.5 Resource Allocation Indication Parameters
The Resource Allocation Indication (RAI) parameters are described in the table below.
Table 58-22: RAI Parameters
Parameter Description
[EnableRAI]
Enables Resource Available Indication (RAI) alarm generation if the
device's busy endpoints exceed a user-defined threshold, configured by
the RAIHighThreshold parameter. When enabled and the threshold is
crossed, the device sends the SNMP trap, acBoardCallResourcesAlarm.
 [0] = (Default) Disable
 [1] = Enable
