User's Manual 592 Document #: LTRT-89730
Mediant 3000
The following procedure describes how to configure Allowed Audio Coder Groups through
the Web interface. You can also configure it through ini file (AllowedCodersGroup).
 To configure an Allowed Coders Group:
1. Open the Allowed Audio Coders Group page (Configuration tab > VoIP menu > SBC
> Allowed Audio Coders Group).
Figure 32-1: Allowed Audio Coders Group Page
2. Configure an Allowed Audio Coders Group according to the parameters described in
the table below.
3. Click Submit.
Table 32-1: Allowed Audio Coders Group Table Parameter Descriptions
Parameter Description
Allowed Audio Coders Group ID
[AllowedCodersGroupX]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
Coder Name
[AllowedCodersGroupX_Name]
Defines the audio coder. This can be a pre-defined coder or a
user-defined coder. The valid value for user-defined coders is a
string of up to 25 characters (case-insensitive). For example,
"HD.123" (without quotes).
Note: Each coder type (e.g., G.729) can be configured only once
per Allowed Coders Group.
32.2 Configuring Allowed Video Coder Groups
The Allowed Video Coders Group table lets you configure up to four Allowed Video Coders
Groups. An Allowed Video Coders Group defines a list of video coders that can be used
when forwarding video streams to a specific SIP entity. Each Allowed Video Coders Group
can be configured with up to 20 coders. The coders can include default video coders and
user-defined (string) video coders for non-standard or unknown coders. Allowed Video
Coders Groups are assigned to SIP entities, using IP Profiles (see ''Configuring IP Profiles''
on page 391). The video coders appear in the SDP media type "video" ('m=video' line).
Coders that are not listed in the Allowed Video Coders Group are removed from the SDP
offer that is sent to the SIP entity. Only coders that are common between the coders in the
