User's Manual 838 Document #: LTRT-89730
Mediant 3000
Parameter Description
Trap Community String
[SNMPTrapCommunityString]
Defines the community string for SNMP traps.
The valid value is a string of up to 19 characters that can include
only the following:
 Upper- and lower-case letters (a to z, and A to Z)
 Numbers (0 to 9)
 Hyphen (-)
 Underline (_)
For example, "Trap-comm_string1".
The default is "trapuser".
SNMP Trusted Managers Table
SNMP Trusted Managers
[SNMPTrustedMgr_x]
Defines up to five IP addresses of remote trusted SNMP managers
from which the SNMP agent accepts and processes SNMP Get
and Set requests.
Notes:
 By default, the SNMP agent accepts SNMP Get and Set
requests from any IP address, as long as the correct
community string is used in the request. Security can be
enhanced by using Trusted Managers, which is an IP address
from which the SNMP agent accepts and processes SNMP
requests.
 If no values are assigned to these parameters any manager
can access the device.
 Trusted managers can work with all community strings.
SNMP V3 Users Table
SNMP V3 Users
[SNMPUsers]
The parameter table defines SNMP v3 users.
The format of the ini file table parameter is:
[SNMPUsers]
FORMAT SNMPUsers_Index = SNMPUsers_Username,
SNMPUsers_AuthProtocol, SNMPUsers_PrivProtocol,
SNMPUsers_AuthKey, SNMPUsers_PrivKey, SNMPUsers_Group;
[\SNMPUsers]
For example:
SNMPUsers 1 = v3admin1, 1, 0, myauthkey, -, 1;
The example above configures user 'v3admin1' with security level
authNoPriv(2), authentication protocol MD5, authentication text
password 'myauthkey', and ReadWriteGroup2.
For a description of the table, see ''Configuring SNMP V3 Users''
on page 112.
58.1.6 Serial Parameters
The serial interface parameters are described in the table below.
Table 58-6: Serial Parameters
Parameter Description
[DisableRS232]
Enables the device's RS-232 (serial) port.
 [0] = (Default) Enabled
To Next Page
