AudioCodes Mediant 3000 User Manual

Version 7.0 255 Mediant 3000
User's Manual 16. Services
3. Click Add; the following dialog box appears:
Figure 16-9: LDAP Search Base DN Table - Add Row Dialog Box
4. Configure an LDAP DN base path according to the parameters described in the table
below.
5. Click Add, and then save ("burn") your settings to flash memory.
Table 16-5: LDAP Server Search Base DN Table Parameter Descriptions
Parameter Description
Index
[LdapServersSearchDNs
_Index]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
Base Path
[LdapServersSearchDNs
_Base_Path]
Defines the full path (DN) to the objects in the AD where the query is
done.
The valid value is a string of up to 256 characters.
For example: OU=NY,DC=OCSR2,DC=local. I
n this example, the DN path
is defined by the LDAP names, OU (organizational unit) and DC (domain
component).
16.3.6 Configuring the LDAP Search Filter Attribute
When the LDAP-based login username-password authentication succeeds, the device
searches the LDAP server for all groups of which the user is a member. The LDAP query is
based on the following LDAP data structure:

Search base object (distinguished name or DN, e.g.,
"ou=ABC,dc=corp,dc=abc,dc=com"): The DN defines the location in the directory
from which the LDAP search begins and is configured in ''Configuring LDAP DNs
(Base Paths) per LDAP Server'' on page
254.

Filter (e.g., "(&(objectClass=person)(sAMAccountName=johnd))"): This filters the
search in the subtree to include only the login username (and excludes others). This is
configured by the 'LDAP Authentication Filter' parameter, as described in the following
procedure. You can use the dollar ($) sign to represent the username. For example,
the filter can be configured as "(sAMAccountName=$)", where if the user attempts to
log in with the username "SueM", the LDAP search is done only for the attribute
sAMAccountName that equals "SueM".

Attribute (e.g., "memberOf") to return from objects that match the filter criteria:
The attribute is configured by the 'Management Attribute' parameter in the LDAP
Configuration table (see ''Configuring LDAP Servers'' on page
250).
Therefore, the LDAP response includes only the groups of which the specific user is a
member.
