AudioCodes Mediant 3000 User Manual

User's Manual 152 Document #: LTRT-89730
Mediant 3000
2. VLANs are required and the Native VLAN ID is the same VLAN ID as the
Management interface (configured for Index 0):
• 'VLAN Mode' is set to Enable.
• 'Native VLAN ID' field is set to "1".
3. Static Route table: A routing rule is required to allow remote management from a
host in 176.85.49.0 / 24:
Table 13-5: Example Static Route Table
Destination Prefix Length Gateway
176.85.49.0 24 192.168.0.1
4. All other parameters are set to their respective default values. The NTP application
remains with its default application types.
13.3.3.3 VoIP Interfaces for Combined Application Types
This example describes the configuration of multiple interfaces for the following
applications:

One interface for the OAMP application.

Interfaces for Call Control and Media applications, where two of them are IPv4
interfaces and one is an IPv6 interface.
1. Interface table:
Table 13-6: Example of VoIP Interfaces of Combined Application Types in Interface Table
Index
Application
Type
Interface
Mode
IP Address
Prefix
Length
Default
Gateway
VLAN
ID
Interface
Name
0 OAMP IPv4
Manual
192.168.85.14 16 192.168.0.1 1 Mgmt
1 Media &
Control
IPv4
Manual
200.200.85.14 24 200.200.85.1 201 MediaCntrl1
2 Media &
Control
IPv4
Manual
200.200.86.14 24 200.200.86.1 202 MediaCntrl2
3 Media &
Control
IPv6
Manual
2000::1:200:2
00:86:14
64 :: 202 V6CntrlMedia2
2. VLANs are required and the Native VLAN ID is the same VLAN ID as the
Management interface (index 0):
• 'VLAN Mode' is set to Enable.
• 'Native VLAN ID' field is set to "1".
3. Static Route table: A routing rule is required to allow remote management from a
host in 176.85.49.0/24:
Table 13-7: Example of Static Route Table
Destination Prefix Length Gateway
176.85.49.0 24 192.168.0.10
