Version 7.0 463 Mediant 3000
User's Manual 23. Trunk Groups
Parameter Description
[TrunkGroup_ProfileName]
For configuring Tel Profiles, see ''Configuring Tel Profiles'' on page 388.
23.2 Configuring Trunk Group Settings Table
The Trunk Group Settings table lets you configure various settings per Trunk Group, which
are configured in the Trunk Group table. The main configuration includes the following:
Channel select method, which defines how the device allocates IP-to-Tel calls to the
channels of a Trunk Group.
Registration method for registering Trunk Groups to remote IP servers (Serving IP
Group).
The Trunk Group Settings table also provides an Action drop-down button with commands
that let you perform various actions per configured Trunk Group:
Lock / Unlock: Locks (blocks) a Trunk Group in order to take its member trunks out-
of-service. For more information, see 'Locking and Unlocking Trunk Groups' on page
675.
Register / Un-Register: Initiates a registration request for the Trunk Group with a
Serving IP Group. For more information, see the description of the 'Registration Mode'
parameter of the Trunk Group Settings table in this section.
The following procedure describes how to configure settings for Trunk Groups through the
Web interface. You can also configure it through ini file (TrunkGroupSettings).
To configure Trunk Group settings:
1. Open the Trunk Group Settings table (Configuration tab > VoIP menu > Gateway >
Trunk Group > Trunk Group Settings).
2. Click Add; the following dialog box appears:
3. Configure a Trunk Group according to the parameters described in the table below.
4. Click Add.
