AudioCodes Mediant 3000 User Manual

Version 7.0 859 Mediant 3000
User's Manual 58. Configuration Parameters Reference
Parameter Description
GwDebugLevel parameter.
Syslog Server IP Address
[SyslogServerIP]
Defines the IP address (in dotted-decimal notation) of the computer on
which the Syslog server is running. The Syslog server is an application
designed to collect the logs and error messages generated by the
device.
The default IP address is 0.0.0.0.
Syslog Server Port
[SyslogServerPort]
Defines the UDP port of the Syslog server.
The valid range is 0 to 65,535. The default port is 514.
CDR Server IP Address
[CDRSyslogServerIP]
Defines the destination IP address to where CDR logs are sent.
The default value is a null string, which causes CDR messages to be
sent with all Syslog messages to the Syslog server.
Notes:
 The CDR messages are sent to UDP port 514 (default Syslog port).
 This mechanism is active only when Syslog is enabled (i.e., the
parameter EnableSyslog is set to 1).
CDR Report Level
[CDRReportLevel]
Enables media and signaling-
related CDRs to be sent to a Syslog server
and determines the call stage at which they are sent.
 [0] None = (Default) CDRs are not used.
 [1] End Call = CDR is sent to the Syslog server at the end of each
call.
 [2] Start & End Call = CDR report is sent to Syslog at the start and
end of each call.
 [3] Connect & End Call = CDR report is sent to Syslog at connection
and at the end of each call.
 [4] Start & End & Connect Call = CDR report is sent to Syslog at the
start, at connection, and at the end of each call.
Notes:
 For the SBC application, the parameter enables only signaling-
related CDRs. To enable media-related CDRs for SBC calls, use the
MediaCDRReportLevel parameter.
 The CDR Syslog message complies with RFC 3164 and is identified
by: Facility = 17 (local1) and Severity = 6 (Informational).
 This mechanism is active only when Syslog is enabled (i.e., the
parameter EnableSyslog is set to 1).
Media CDR Report Level
[MediaCDRReportLevel]
Enables media-related CDRs of SBC calls to be sent to a Syslog server
and determines the call stage at which they are sent.
 [0] None = (Default) No media-related CDR is sent.
 [1] End Media = Sends a CDR only at the end of the call.
 [2] Start & End Media = Sends a CDR once the medi
a starts. In some
calls it may only be after the call is established, but in other calls the
media may start at ringback tone. A CDR is also sent upon
termination (end) of the media in the call.
 [3] Update & End Media = Sends a CDR when an update occurs in
the media of the call. For example, a call starts and a ringback tone
occurs, a re-INVITE is sent for a fax call and as a result, a CDR with
the MediaReportType field set to "Update" is sent, as the media was
changed from voice to T.38. A CDR is also sent upon termination
