GE Voluson i BT06 User Manual

GE VOLUSON i / VOLUSON e
D
IRECTION KTI106052, REVISION 10 SERVICE MANUAL
3-48 Section 3-5 - Connection of Auxiliary Devices
3-5-7-5-1 After physical connection
1.) Press the USB
button on the keyboard.
The “Connect USB and Network Drives” dialog window appears (Figure 3-61 below).
2.) If the [Connect to] field shows not used (see: Figure 3-61, above), double-click the “DVD line”.
3.) Click on the arrow icon below the [Connect to] field and select DVD/CD rec from the pop-up menu.
4.) CLOSE
the dialog window.
Figure 3-61 DVD drive “not used”
BT Version:
BT-Version:
If an external drive was not recognized automatically after connecting it, click RESCAN DRIVE only on
systems with BT’07 software.(see:Figure 3-56 on page 3-44)
Figure 3-62 change to “DVD/CD rec”
arrow icon to open
the pop-up menu
