GE VOLUSON i / VOLUSON e
D
IRECTION KTI106052, REVISION 10 SERVICE MANUAL
5-42 Section 5-8 - Peripherals
Section 5-8
Peripherals
5-8-1 Introduction
The following peripherals are used with the Voluson i / Voluson e portable ultrasound system:
• VCR (connected via VGA-to-video converter)
• DVD recorder (connected via VGA-to-video converter)
• Black & White Digital Printer (connected via USB)
• Color Digital Printer (connected via USB)
• Color Deskjet Printer (via Bluetooth Adapter)
• Bluetooth Adapter (connected via USB)
• DVD+R/RW (connected via USB)
• USB Flash Memory device 512MB (connected via USB)
• Wireless Network Adapter (connected via PCMCIA)
• Wireless Network Interface (connected via USB port)
• Footswitch
5-8-1-1 Recording Tools
5-8-1-1-1 VCR and Video Converter
The VCR is controlled from the units front panel. Operation is completely independent of the
Voluson i / Voluson e system. One must obtain the appropriate PAL or NTSC VCR in accordance
with the regional standards. The VCR is connected to the system via a VGA-to-video converter; the
video converter must be set up to fit the regional standards.
For details see Figure 3-72 on page 3-57.
In some regions, the VCR is used as an official patient information back-up device. To obtain the
maximum image quality it is recommended to use S-VHS video tapes and make sure that the VCR
is setup for High Quality recording.
5-8-1-1-2 DVD Recorder and Video Converter
The DVD recorder is controlled from the units front panel. Operation is completely independent of
the Voluson i / Voluson e system. The DVD recorder is connected to the system via a VGA-to-video
converter; the video converter must be set up to fit the regional standards.
For details see Figure 3-77 on page 3-62.
5-8-1-2 Printers
5-8-1-2-1 Black & White Digital Printer
The B&W Printer receives image data via the USB port. The print command is controlled by the
keys P1
, P2 or P3 on the Voluson i / Voluson e control panel (depends on system configuration).
5-8-1-2-2 Color Digital Printer
The Color Printer receives image data via the USB port. The print command is controlled by the
keys P1
, P2 or P3 on the Voluson i / Voluson e control panel (depends on system configuration).
5-8-1-2-3 Color Deskjet Printer
Normally, a Color Deskjet Printer is used to print out reports and exams, but in some cases also
ultrasound images. It is controlled via Bluetooth Adapter.
