GE VOLUSON

i / VOLUSON

IRECTION KTI106052, REVISION 10 SERVICE MANUAL

Chapter 5 - Components and Functions (Theory) 5-41

Section 5-7

Display Module and LCD Monitor

The Voluson i / Voluson e´s Display Module (GPD) consists of the 15” LCD Monitor in XGA (Extended

Graphic Array) technology with built-in backlight lamp, flex connector board to the instrument, backlight

inverter board, microphone (not available with SW 8.1.2 and higher),

lid switch magnetic and the mechanical parts.
