GE VOLUSON
i / VOLUSON
e
D
IRECTION KTI106052, REVISION 10 SERVICE MANUAL
8-76 Section 8-20 - Replacement of the Voluson Station Components
8-20-16 Replacement of the Column Label Cover
8-20-16-1 Manpower
One person, 15 minutes
8-20-16-2 Tools
Phillips screwdriver 1
8-20-16-3 Preparations
1.) Power Off/Shutdown the system as described in Section 3-6-3 on page 3-72.
2.) Remove the Top Shelf Additional Bottom Cover as described in Section 8-20-12 on page 8-72 or
remove the optional Probe Mux Bos as described in Section 8-20-9 on page 8-68.
3.) Remove the Top Shelf Bottom Rear Cover as described in Section 8-20-13 on page 8-73.
4.) Remove the Top Column Back Cover as descibed in Section 8-20-14 on page 8-74.
8-20-16-4 Column Label Cover - Removal Procedure
1.) Carefully remove the Column Label Cover.
8-20-16-5 Column Label Cover - Installation Procedure
1.) Place the new Column Label Cover.
2.) Mount the Top Column Back Cover as descibed in Section 8-20-14-5 on page 8-74.
3.) Mount the Top Shelf Bottom Rear Cover as described in Section 8-20-13-5 on page 8-73.
4.) Mount the Top Shelf Additional Bottom Cover as described in Section 8-20-12-5 on page 8-72 or
mount the optional Probe Mux Box as described in Section 8-20-9-5 on page 8-69.
