GE VOLUSON
i / VOLUSON
e
D
IRECTION KTI106052, REVISION 10 SERVICE MANUAL
Chapter 5 - Components and Functions (Theory) 5-19
5-3-2 Radio Frequency Interface (RBI) Board
The Radio Frequency Interface (RBI) Board combines the following sub-boards and functionalities:
FEC (Front End Controller)
RFT (Radio Frequency & Tissue) processor
IMP (Image Port)
5-3-2-1 Tasks Performed by the RBI Board
System Master Clock generator
Transmitter Control
ATGC Control
Receive Focusing Control
Analog Test Signal Generator
High Voltage Control and supervision
Probe Sensing
Control of MUX board and RBF boards
NOTE: Additional Coax Cable need to be used and connected if system is equipped with GPP5/GPP6 and
RBI4 (See connection on GPP and RBI (Figure 5-6, above).
Not using the cable shows slight PW-mode disturbances. The Coax Cable prevents it.
5-3-3 RBF Boards (Transmitter/Receiver)
The Transmitter/Receiver has 64 channels and is made up of two identical RBF boards.
Each RBF board is a complete 32-channel ultrasound Front End that includes the following features
and functions:
32 Transmitters
32 Receiving channels, T/R switch, Pre-Amp, TGC, ADC
32 channel digital Beamformer
