T200 User's Manual SECTION 7: WINDRIVE
PAGE 7-34
7.10.1.3 Reference Source Selection
The servo-drive’s reference source is chosen using the Reference Source Dialog Box shown below. Reference sources
are explained in Section 6. Note that the reference rate limits are also outlined in that section.
Figure 7.34: Reference Source Dialog Box
NOTE - When the Motor Type is set to standard, the Remove Motor, Add Motor and Edit features are
- G40X series MOOG motors usually have an equivalent standard MOOG motor.
The G40X
motors and their equivalent standard motors have the same electrical parameters, though may differ in
mechanical configuration. The T200 only needs to be configured with the correct electrical parameters.
Consult the MOOG sales outlet for information on the equivalent standard motor. If this equivalent is
known, the standard motor may be entered instead of a non-standard motor.
