T200 User's Manual SECTION 3: WIRING AND INSTALLATION
PAGE 3-22
3.3 Power Dissipation
To calculate cabinet cooling requirements, Table 3.3 provides approximate equipment power dissipation values. If the
application employs regeneration, be sure to add the regen resistor power dissipation to the numbers quoted in Table 3.3
below, (use the continuous wattage rating of the regen resistor if the actual application regen dissipation is unknown).
Power Dissipation (Watts)% of rated
continuous
output
current
T200-
300
[W]
T200-
310
[W]
T200-
400
[W]
T200-
410
[W]
T200-
500
[W]
T200-
510
[W]
T200-
610
[W]
T200-
710
[W]
0 35 48 35 48 35 50 50 50
25 50 63 65 80 100 110 130 175
50 65 78 100 110 165 180 220 300
75 80 93 130 140 225 240 300 430
100 97 110 160 175 290 300 400 550
Table 3.3:- Estimated Power Dissipation for the T200 Servo-drives
