Zynq-7000 AP SoC and 7 Series FPGAs MIS v4.1 484
UG586 November 30, 2016
www.xilinx.com
Chapter 3: RLDRAM II and RLDRAM 3 Memory Interface Solutions
Simulation Flow Using IES and VCS Script Files
To run the simulation, go to this directory:
<project_dir>/<Component_Name>_ex/imports
For a project created with the name set as project_1 and the Component Name entered
in Vivado IDE as mig_7series_0, go to the directory as follows:
project_1/mig_7series_0_ex/imports
IES and VCS simulation scripts are meant to be executed only in Linux operating systems.
The ies_run.sh and vcs_run.sh files are the executable files for running simulations
using IES and VCS simulators respectively. Library files should be added to the
ies_run.sh and vcs_run.sh files respectively. See the readme.txt file for details
regarding simulations using IES and VCS.
Simulation Flow Using Vivado Simulator
1. In the Open IP Example Design Vivado project, under Flow Navigator, select
Simulation Settings (Figure 3-64).
