Chapter 4: LPDDR2 SDRAM Memory Interface Solution
The top-level wrapper file serves as an example for connecting the user_design to the
7 series FPGA memory interface core.
user_design/rtl/clocking
This directory contains the user design (Table 4-5).
user_design/rtl/controller
This directory contains the Memory Controller that is instantiated in the example design
(Table 4-6).
Table 4-5: Modules in user_design/rtl/clocking Directory
Name
(1)
Description
clk_ibuf.v This module instantiates the input clock buffer.
iodelay_ctrl.v
This module instantiates IDELAYCNTRL primitives needed for
IDELAY use.
infrastructure.v
This module helps in clock generation and distribution, and reset
synchronization.
Notes:
1. All file names are prefixed with the MIG version number. For example, for the MIG 4.1 release module name of
clk_ibuf in generated output is now mig_7series_v4_1_clk_ibuf.
Table 4-6: Modules in user_design/rtl/controller Directory
Name
(1)
Description
arb_mux.v This is the top-level module of arbitration logic.
arb_row_col.v
This block receives requests to send row and column commands from the
bank machines and selects one request, if any, for each state.
arb_select.v
This module selects a row and column command from the request
information provided by the bank machines.
bank_cntrl.v
This structural block instantiates the three subblocks that comprise the
bank machine.
bank_common.v This module computes various items that cross all of the bank machines.
bank_compare.v This module stores the request for a bank machine.
bank_mach.v This is the top-level bank machine block.
bank_queue.v This is the bank machine queue controller.
bank_state.v This is the primary bank state machine.
col_mach.v This module manages the DQ bus.
mc.v This is the top-level module of the Memory Controller.
mem_intfc.v
This top-level memory interface block instantiates the controller and the
PHY.
rank_cntrl.v This module manages various rank-level timing parameters.
