AudioCodes Mediant 2000 System User Manual

Version 5.2 125 September 2007
SIP User's Manual 5. Web-based Management
Table 5-20: Tel to IP Routing Table
Parameter Description
Tel to IP Routing Mode
[RouteModeTel2IP]
Defines the order between routing incoming calls to IP, using routing table,
and manipulation of destination number.
 [0] Route calls before manipulation = Tel-to-IP calls are routed before
the number manipulation rules are applied (default).
 [1] Route calls after manipulation = Tel-to-IP calls are routed after the
number manipulation rules are applied.
Note: Not applicable if outbound Proxy routing is used.
Dest. Phone Prefix
Represents a called telephone number prefix. The prefix can be 1 to 19
digits long. An asterisk (*) represents all numbers.
Source Phone Prefix
Represents a calling telephone number prefix. The prefix can be 1 to 19
digits long. An asterisk (*) represents all numbers.
Any telephone number whose destination number matches the prefix defined in the 'Dest. Phone
Prefix' field and its source number matches the prefix defined in the adjacent 'Source Phone Prefix'
field is sent to the IP address entered in the 'Dest. IP Address' field.
Notes:
 Tel to IP routing can be performed according to a combination of source and destination phone
prefixes, or using each independently.
 An additional entry of the same prefixes can be assigned to enable alternative routing.
 For available notations that represent multiple numbers, refer to 'Dialing Plan Notation' on page
116.
Dest. IP Address
The IP address (and optionally port number) assigned to the prefix. For
example, <IP Address>:<Port>.
Domain names such as domain.com, can be used instead of IP addresses.
To discard outgoing IP calls, enter 0.0.0.0.
Note: When using domain names, you must enter a DNS server IP
address or alternatively, define these names in the 'Internal DNS Table'.
Profile ID
IP profile number assigned to the destination IP address that is defined in
the 'Dest. IP Address' field.
Status
A read-only field representing the Quality of Service of the destination IP
address:
 n/a = Alternative Routing feature is disabled.
 OK = IP route is available
 Ping Error = No ping to IP destination; route is not available
 QoS Low = Bad QoS of IP destination; route is not available
 DNS Error = No DNS resolution (only when domain name is used
instead of an IP address).
