SIP User's Manual 60 Document #: LTRT-68806
Mediant 2000 & TP-1610 & TP-260/UNI
5.3 Accessing the Embedded Web Server
You can access the gateway's Embedded Web Server by following the procedure below.
¾ To access the Embedded Web Server, take these 4 steps:
1. Open a standard Web-browsing application (for a list of supported Web browsers,
refer to 'Computer Requirements' on page 57).
2. In the Web browser's Uniform Resource Locator (URL) field, specify the gateway's IP
address (e.g., http://10.1.10.10); the Embedded Web Server's 'Enter Network
Password' screen appears, as shown in the figure below.
Figure 5-1: Enter Network Password Screen
3. In the 'User Name' and 'Password' fields, enter the username (default: 'Admin') and
password (default: 'Admin'). Note that the username and password are case-sensitive.
4. Click the OK button; the Embedded Web Server is accessed, displaying the Home
page (for a detailed description of the Home page, refer to Using the Home Page on
page 260).
Note: If access to the gateway's Embedded Web Server is denied ("Unauthorized")
due to Microsoft Internet Explorer security settings, perform the following
troubleshooting procedures:
1. Delete all cookies in the Temporary Internet Files folder. If this does not
resolve the problem, the security settings may need to be altered
(continue with Step 2).
2. In Internet Explorer, navigate to Tools menu > Internet Options >
Security tab > Custom Level, and then scroll down to the Logon options
and select Prompt for username and password. Select the Advanced
tab, and then scroll down until the HTTP 1.1 Settings are displayed and
verify that Use HTTP 1.1 is selected.
3. Quit and start the Web browser again.
