Version 5.2 401 September 2007
SIP User's Manual 11. Selected Technical Specifications
11.4 TP-260 Specifications
Table 11-4: TP-260 Selected Technical Specifications
Function Specification
Trunk & Channel Capacity
Capacity with E1
1, 2, 4 or 8 E1 spans, 30, 60, 120 or 240 digital channels
Note: TP-260 channel capacity depends on configuration settings.
Capacity with T1
1, 2, 4 or 8 T1 spans, 24, 48, 96 or 192 digital channels
Note: TP-260 channel capacity depends on configuration settings.
Interfaces
PCI
Universal PCI 33/66 MHz, 32/64-bit, 3.3/5V signaling blade
Telephony
Up to eight 120-ohm RJ-48C connectors (with adaptor)
Network
Ethernet RJ-45 connector, 10/100 Base-TX
LED Indicators
LEDs
T1/E1 status, LAN status
Physical
Form Factor
Full length single slot PCI card
Supply Voltages and
Power Consumption
(typical)
8 trunks/240 channels - 18 W (3.6 A at 5V)
Environmental
Humidity: 10 to 90% non-condensing
Cooling Requirement
500 LFM at 50 °C ambient temp. supporting 8 ports
Type Approvals
Safety and EMC
Standards
UL 60950, FCC part 15 Class B, CE Mark (EN55022, EN60950,
EN55024)
