SIP User's Manual 232 Document #: LTRT-68806
Mediant 2000 & TP-1610 & TP-260/UNI
Table 5-52: Call Routing Status Parameters
Parameter Description
Current Call-Routing Method
 Proxy = Proxy server is used to route calls.
 Routing Table preferred to Proxy = The Tel to IP Routing table
takes precedence over a Proxy for routing calls
(PreferRouteTable = 1).
 Routing Table = The Tel to IP Routing table is used to route
calls.
Current Proxy
 Not Used = Proxy server isn't defined.
 IP address and FQDN (if exists) of the Proxy server the gateway
currently operates with.
Current Proxy State
 N/A = Proxy server isn't defined.
 OK = Communication with the Proxy server is in order.
 Fail = No response from any of the defined Proxies.
5.11.1.4 SAS Registered Users
The 'SAS Registered Users' screen provides you with a list of up to SAS Registered
Users.
¾ To view the 'SAS Registered Users' screen, take this step:
îš„ Open the 'SAS Registered Users' screen (Status & Diagnostics menu > Gateway
Statistics submenu > SAS Registered Users option).
Figure 5-51: SAS Registered Users Screen
Table 5-53: SAS Registered Users Parameters
Column Name Description
Address of Record
An address-of-record (AOR) is a SIP or SIPS URI that points to a domain with a
location service that can map the URI to another URI (Contact) where the user
might be available.
Contact
SIP URI that can be used to contact that specific instance of the UA for
subsequent requests.
