SIP User's Manual 136 Document #: LTRT-68806
Mediant 2000 & TP-1610 & TP-260/UNI
5. Configure the Profile's parameters according to your requirements. For detailed
information on each parameter, refer to the description of the screen in which it is
configured as an individual parameter.
6. From the 'Coder Group' drop-down list, select the coder group to which you want to
assign the Profile. You can select the gateway's default coders (refer to 'Coders' on
page 96) or one of the coder groups you defined in the 'Coder Group Settings' screen
(refer to 'Coder Group Settings' on page 133).
7. Repeat steps 2 to 6 for the second to fifth Tel Profiles (optional).
8. Click the Submit button to save your changes.
9. To save the changes to flash memory, refer to 'Saving Configuration' on page 256.
5.5.5.3 IP Profile Settings
The IP Profile Settings option is used to define up to four different IP Profiles. These
Profiles are used in the 'Tel to IP Routing' and 'IP to Trunk Group Routing Table' screens
for associating IP Profiles to routing rules. IP Profiles can also be used when working with
Proxy server (set AlwaysUseRouteTable to 1).
You can also configure the IP Profiles using the ini file parameter IPProfile (refer to 'SIP
Configuration Parameters' on page 295).
