AudioCodes Mediant 2000 System User Manual

Version 5.2 69 September 2007
SIP User's Manual 5. Web-based Management
¾ To replace the background image via the ini file, take these 3
steps:
1. Place your background image file in the same folder as where the device’s ini file is
located (i.e., the same location defined in the BootP/TFTP configuration utility). For
detailed information on the BootP/TFTP, refer to the SIP Series Reference Manual).
2. Add or modify the ini file parameters listed in the table below (according to the
procedure described in 'Modifying an ini File' on page 267).
3. Load the ini file using only BootP / TFTP (i.e., not through the Embedded Web
Server).
Table 5-5: Customizable Logo ini File Parameters
Parameter Description
BkgImageFileName
The name (and path) of the file containing the new background.
Use a gif, jpg or jpeg image file.
The default is AudioCodes background file.
Note: The length of the name of the image file is limited to 47 characters.
5.4.5.3 Customizing the Product Name
To replace AudioCodes’ default product name with a text string, add or modify the two ini
file parameters listed in the table below (according to the procedure described in' Modifying
an ini File' on page 267).
Table 5-6: Web Appearance Customizable ini File Parameters
Parameter Description
UseProductName
 [0] = Don’t change the product name (default).
 [1] = Enable product name change.
UserProductName
Text string that replaces the product name.
The default is ‘Mediant 2000’.
The string can be up to 29 characters.
