Version 5.2 231 September 2007
SIP User's Manual 5. Web-based Management
Table 5-51: Call Counters Description
Counter Description
Number of Failed
Calls due to No
Resources
Indicates the number of calls that failed due to unavailable resources or a
gateway lock. The counter is incremented as a result of one of the following
release reasons:
 GWAPP_RESOURCE_UNAVAILABLE_UNSPECIFIED
 RELEASE_BECAUSE_GW_LOCKED
Number of Failed
Calls due to Other
Failures
This counter is incremented as a result of calls that fail due to reasons not
covered by the other counters.
Average Call
Duration (ACD)
[sec]
The average call duration of established calls.
Attempted Fax
Calls Counter
Indicates the number of attempted fax calls.
Successful Fax
Calls Counter
Indicates the number of successful fax calls.
5.11.1.3 Call Routing Status
The 'Call Routing Status' screen provides you with information on the current routing
method used by the gateway. This information includes the IP address and FQDN (if used)
of the Proxy server with which the gateway currently operates.
¾ To view the 'Call Routing Status' screen, take this step:
îš„ Open the 'Call Routing Status' screen (Status & Diagnostics menu > Gateway
Statistics submenu > Calls Routing Status option).
Figure 5-50: Call Routing Status Screen
