SIP User's Manual 164 Document #: LTRT-68806
Mediant 2000 & TP-1610 & TP-260/UNI
5.6.5 Configuring the VLAN Settings
For detailed information on the gateway VLAN implementation, refer to 'VLANS and
Multiple IPs' on page 373.
¾ To configure the VLAN Settings parameters, take these 4 steps:
1. Open the 'VLAN Settings' screen (Advanced Configuration menu > Network
Settings > VLAN Settings option).
Figure 5-32: VLAN Settings Screen
2. Configure the VLAN Settings according to the table below.
3. Click the Submit button to save your changes.
4. To save the changes to flash memory, refer to 'Saving Configuration' on page 256.
Table 5-31: Network Settings -- VLAN Settings Parameters
Parameter Description
VLAN Mode
[VlANMode]
Sets the VLAN functionality.
 [0] Disable (default).
 [1] Enable.
 [2] PassThrough = N/A.
Note: This parameter cannot be changed on-the-fly
and requires a gateway reset.
