SIP User's Manual 5. Web-based Management
Table 5-23: Hunt Group Settings Parameters
Mode Description
Trunk Group ID
Trunk Group ID to which you want to determine the method in which new calls
are assigned to channels within the trunk group.
Channel Select
Mode
Method in which new calls are assigned to channels within the Trunk Group
entered in the 'Trunk Group ID' field:
 By Dest Phone Number = Selects the gateway port according to the called
number (refer to the note below).
 Cyclic Ascending = Selects the next available channel in an ascending cycle
order. Always select the next higher channel number in the Trunk Group.
When the gateway reaches the highest channel number in the Trunk Group,
it selects the lowest channel number in the Trunk Group and then starts
ascending again (default).
 Ascending = Selects the lowest available channel. It always starts at the
lowest channel number in the Trunk Group and if that channel is not
available, it selects the next higher channel.
 Cyclic Descending = Selects the next available channel in descending cycle
order. It always selects the next lower channel number in the Trunk Group.
When the gateway reaches the lowest channel number in the Trunk Group,
it selects the highest channel number in the Trunk Group and then start
descending again.
 Descending = Selects the highest available channel. It always starts at the
highest channel number in the Trunk Group and if that channel is not
available, selects the next lower channel.
 Dest Number + Cyclic Ascending = It first selects the gateway port according
to the called number (refer to the note below). If the called number isn't
found, then it selects the next available channel in ascending cyclic order.
Note that if the called number is found, but the port associated with this
number is busy, the call is released.
 By Source Phone Number = Selects the gateway port according to the
calling number.
 Trunk Cyclic Ascending = Selects the gateway port from the first channel of
the next trunk (next to the trunk from which the previous channel was
allocated).
Registration Mode
Registration mode for the Trunk Group:
 Per Endpoint = separate registration for each channel in the Trunk Group.
 Per Gateway = single registration for the whole Trunk Group (default).
 Don't Register
Note: The internal numbers of the gateway's channels are defined in the 'Trunk
Group Table' under the 'Phone Number' column. For detailed information on
the 'Trunk Group Table', refer to 'Configuring the Trunk Group Table' on page
138).
