Version 5.2 337 September 2007
SIP User's Manual 6. ini File Configuration
6.5.14 Configuration Files Parameters
The configuration files (i.e., auxiliary files) can be loaded to the gateway using the
Embedded Web Server or a TFTP session (refer to 'Auxiliary Files' on page 247). Before
you load them to the gateway, in the ini file you need to specify the files that you want
loaded and whether they must be stored in the non-volatile memory. The table below lists
the ini file parameters associated with these configuration files:
Table 6-14: Configuration Files Parameters
ini File Field Name Valid Range and Description
CallProgressTonesFilename
The name of the file containing the Call Progress Tones definitions.
Refer to the SIP Series Reference Manual for additional information
on how to create and load this file.
CASFileName
This is the name of the file containing specific CAS protocol definition
(such as 'E_M_WinkTable.dat'). These files are provided to support
various types of CAS signaling.
CASFileName_x
CAS file name (e.g., 'E_M_WinkTable.dat') that defines the CAS
protocol. It is possible to define up to eight different CAS files by
repeating this parameter. Each CAS file can be associated with one or
more of the gateway trunks using the parameter CASTableIndex_x.
CASTablesNum
Number, 1 to 8. Specifies how many CAS configuration files are
loaded.
VoicePromptsFileName
The name (and path) of the file containing the Voice Prompts
definitions. Refer to the SIP Series Reference Manual for additional
information on how to create and load this file.
PrerecordedTonesFileName
The name (and path) of the file containing the Prerecorded Tones.
CasTrunkDialPlanName
The Dial Plan name (up to 11-character strings) that is used on the
specific trunk.
DialPlanFileName
The name (and path) of the file containing dial-plan configuration for
CAS and SIP protocols. This file should be constructed using the
TrunkPack Conversion Utility (refer to the SIP Series Reference
Manual) supplied as part of the software package on the CD
accompanying the gateway.
UserInfoFileName
The name (and path) of the file containing the User Information data.
SaveConfiguration
Determines if the gateway's configuration (parameters and files) is
saved to flash (non-volatile memory).
 [0] = Configuration isn't saved to flash memory.
 [1] = Configuration is saved to flash memory (default).
