8.10.3.2 Integrating Using the ini File
The procedure below describes how to integrate the gateway into a VLAN and multiple IPs
network using the ini file.
¾ To integrate the gateway into a VLAN and multiple IPs network
using the ini file, take these 3 steps:
1. Prepare an ini file with relevant parameters. Refer to the following notes:
• If the BootP/TFTP utility and the OAM interface are located in the same network,
the Native VLAN ID (VlanNativeVlanId) must be equal to the OAM VLAN ID
(VlanOamVlanId), which in turn must be equal to the PVID of the switch port to
which the gateway is connected. Therefore, set the PVID of the switch port to 4
(in this example).
• Configure the OAM parameters (LocalOAMPAddress, LocalOAMSubnetMask
and LocalOAMDefaultGW) only if the OAM networking parameters are different
from the networking parameters used in the Single IP Network mode.
• The IP Routing table is required to define static routing rules for the OAM and
Control networks since a default gateway isn’t supported for these networks.
Below is an example of an ini file containing VLAN and Multiple IPs parameters:
; VLAN Configuration
VlanMode=1
VlanOamVlanId=4
VlanNativeVlanId=4
VlanControlVlanId=5
VlanMediaVlanID=6
; Multiple IPs Configuration
EnableMultipleIPs=1
LocalMediaIPAddress=10.33.174.50
LocalMediaSubnetMask=255.255.0.0
LocalMediaDefaultGW=10.33.0.1
LocalControlIPAddress=10.32.174.50
LocalControlSubnetMask=255.255.0.0
LocalControlDefaultGW=0.0.0.0
LocalOAMPAddress=10.31.174.50
LocalOAMSubnetMask=255.255.0.0
LocalOAMDefaultGW=0.0.0.0
; IP Routing table parameters
RoutingTableDestinationsColumn = 130.33.4.6, 83.4.87.6
RoutingTableDestinationMasksColumn = 255.255.255.255 ,
255.255.255.0
RoutingTableGatewaysColumn = 10.32.0.1 , 10.31.0.1
RoutingTableInterfacesColumn = 1 , 0
RoutingTableHopsCountColumn = 20,20
2. Use the BootP/TFTP utility (refer to the SIP Series Reference Manual) to load and
burn (-fb option) the firmware version and the ini file you prepared in the previous step
to the gateway (VLANs and multiple IPs support is available only when the firmware is
burned to flash).
3. Reset the gateway after disabling it on the BootP/TFTP utility.
