Version 5.2 377 September 2007
SIP User's Manual 8. Networking Capabilities
b. Modify the VLAN parameters to correspond to the values shown in the following
figure.
Figure 8-1: VLAN Settings Screen - Example
c. Click the Submit button to save your changes.
4. Configure the multiple IP parameters by completing the following steps:
a. Open the ‘IP Settings’ screen (Advanced Configuration menu > Network
Settings > IP Settings option).
b. Modify the IP parameters to correspond to the values shown in the figure below.
Note that the OAM, Control, and Media Network Settings parameters appear only
after you select the options ‘Multiple IP Networks’ or 'Dual IP' in the field ‘IP
Networking Mode’.
Note: Configure the OAM parameters only if the OAM networking parameters are
different from the networking parameters used in the Single IP Network mode.
