SIP User's Manual 182 Document #: LTRT-68806
Mediant 2000 & TP-1610 & TP-260/UNI
Table 5-37: E1/T1/J1 Configuration Parameters
ini File Field Name
Web Parameter Name
Valid Range and Description
Protocol Type
[ProtocolType]
Sets the PSTN protocol to be used for this trunk.
 [1] E1 EURO ISDN
 [2] T1 CAS
 [3] T1 RAW CAS
 [4] T1 TRANSPARENT
 [5] E1 TRANSPARENT 31
 [6] E1 TRANSPARENT 30
 [7] E1 MFCR2
 [8] E1 CAS
 [9] E1 RAW CAS
 [10] T1 NI2 ISDN
 [11] T1 4ESS ISDN
 [12] T1 5ESS 9 ISDN
 [13] T1 5ESS 10 ISDN
 [14] T1 DMS100 ISDN
 [15] J1 TRANSPARENT
 [16] T1 NTT ISDN = Japan - Nippon Telegraph
 [17] E1 AUSTEL ISDN = Australian Telecom
 [18] T1 HKT ISDN = Hong Kong - HKT
 [19] E1 KOR ISDN = Korean operator
 [20] T1 HKT ISDN = Hong Kong - HKT over T1
 [21] E1 QSIG
 [23] T1 QSIG
 [31] E1 FRENCH VN3 ISDN
 [35] T1 DMS100 Meridian ISDN
 [40] E1 NI2 ISDN
 [41] E1 CAS R15
Note: The gateway simultaneously supports different variants of CAS
and PRI protocols on different E1/T1 spans (no more than four
simultaneous PRI variants).
Clock Master
[ClockMaster]
Determines the Tx clock source of the E1/T1 line.
 [0] Recovered = Generate the clock according to the Rx of the E1/T1
line (default).
 [1] Generated = Generate the clock according to the internal TDM
bus.
For detailed information on configuring the gateway's clock settings, refer
to 'Clock Settings' on page 381.
Note: The source of the internal TDM bus clock is determined by the
parameter TDMBusClockSource.
