Table 5-27: Network Settings -- IP Settings Parameters
Parameter Description
IP Networking Mode
[EnableMultipleIPs]
Enables / disables the Multiple IPs mechanism.
 [0] Single IP Network = Single IP network (default).
 [1] Multiple IP Network = Multiple IP networks.
 [1] Dual IP (Media & Control) = Multiple IP networks.
 [1] Dual IP (OAM & Control) = Multiple IP networks.
 [1] Dual IP (OAM & Medial) = Multiple IP networks.
For detailed information on Multiple IPs, refer to 'Multiple IPs' on page
373.
IP Address IP address of the gateway.
Enter the IP address in dotted format notation, for example 10.8.201.1.
Notes:
 A warning message is displayed (after clicking the button Submit) if
the entered value is incorrect.
 After changing the IP address you must reset the gateway.
Subnet Mask Subnet mask of the gateway.
Enter the subnet mask in dotted format notation, for example
255.255.0.0
Notes:
 A warning message is displayed (after clicking the button Submit) if
the entered value is incorrect.
 After changing the subnet mask, the gateway must be reset.
Default Gateway Address IP address of the default gateway used by the gateway.
Enter the IP address in dotted format notation, for example 10.8.0.1.
Notes:
 A warning message is displayed (after clicking the button Submit) if
the entered value is incorrect.

A
fter changing the default gateway IP address, the gateway must be
reset.
For detailed information on multiple routers support, refer to 'Multiple
Routers Support' on page 371.
OAM Network Settings (available only in Multiple IPs and Dual IP modes)
IP Address
[LocalOAMIPAddress]
The gateway's source IP address in the OAM network.
The default value is 0.0.0.0.
Subnet Mask
[LocalOAMSubnetMask]
The gateway's subnet mask in the OAM network.
The default subnet mask is 0.0.0.0.
Default Gateway Address
[LocalOAMDefaultGW]
N/A. Use the IP Routing table instead (refer to 'Configuring the IP
Routing Table' on page 162).
Control Network Settings (available only in Multiple IPs and Dual IP modes)
IP Address
[LocalControlIPAddress]
The gateway's source IP address in the Control network.
The default value is 0.0.0.0.
Subnet Mask
[LocalControlSubnetMask]
The gateway's subnet mask in the Control network.
The default subnet mask is 0.0.0.0.
