SIP User's Manual 52 Document #: LTRT-68806
Mediant 2000 & TP-1610 & TP-260/UNI
4.3.3.1 Accessing the CLI
The procedure below describes how to access the CLI using either Telnet or RS-232
interface (if supported).
¾ To access the CLI using the embedded Telnet server, take these 3
steps:
1. Enable the embedded Telnet server, by performing the following:
a. Access the gateway's Embedded Web Server (refer to 'Accessing the Embedded
Web Server' on page 60).
b. Open the 'Application Settings' screen (Advanced Configuration menu >
Network Settings > Application Settings option), and therein set the parameter
‘Embedded Telnet Server’ to ‘Enable (Unsecured)’ or ‘Enable Secured (SSL)’.
For detailed information, refer to 'Configuring the Application Settings' on page
157.
c. Save these settings to the flash memory and reset the gateway by performing the
following:
a. Click the Maintenance button on the main menu bar; the 'Maintenance
Actions' screen is displayed.
b. From the 'Burn to FLASH' drop-down list, select 'Yes', and then click the
Reset button; the gateway shuts down and restarts.
2. Use a standard Telnet application to connect to the gateway's embedded Telnet
server. Note that if the Telnet server is set to SSL mode, a special Telnet client is
required on your PC to connect to the Telnet interface over a secured connection.
3. Login using the default username (‘Admin’) and password (‘Admin’).
The procedure below describes how to establish a serial communications link with the
gateway (using serial communication software such as HyperTerminal
TM
) through the RS-
232 interface.
¾ To access the CLI using the RS-232 port (if supported), take these
2 steps:
1. Connect the gateway's RS-232 port to your PC (refer to Connecting the RS-232 Port
to Your PC on page 37.
2. Use a serial communication software (e.g., HyperTerminal
TM
) with the following
communications port settings:
• Baud Rate: 115,200 bps
• Data bits: 8
• Parity: None
• Stop bits: 1
• Flow control: None
The CLI prompt appears.
Note: The TP-1610 and TP-260 don't provide an RS-232 port.
