Version 5.2 399 September 2007
SIP User's Manual 11. Selected Technical Specifications
11.3 TP-1610 Specifications
Table 11-3: TP-1610 Selected Technical Specifications
Function Specification
Trunk & Channel Capacity
Capacity with E1
1, 2, 4, 8 or 16 E1 spans, 30, 60, 120, 240 or 480 digital channels
30 Channels on 1 E1 span with gateway-1 only
60 Channels on 2 E1 spans with gateway-1 only
120 Channels on 4 E1 spans with gateway-1 only
240 Channels on 8 E1 spans with gateway-1 only
480 Channels on 16 E1 spans with gateway-1 and gateway-2
Note: TP-1610 channel capacity depends on configuration settings.
Capacity with T1
1, 2, 4, 8 or 16 T1 spans, 24, 48, 96, 192 or 384 digital channels
24 Channels on 1 T1 span with gateway-1 only
48 Channels on 2 T1 spans with gateway-1 only
96 Channels on 4 T1 spans with gateway-1 only
192 Channels on 8 T1 spans with gateway-1 only
384 Channels on 16 T1 spans with gateway-1 and gateway-2
Note: TP-1610 channel capacity depends on configuration settings.
Processor
Control Processor
Motorola PowerQUICC 8260
Control Processor
Memory
SDRAM 64* - 128 MB (*on 60-channel models)
Signal Processors
AudioCodes AC486 VoIP DSP based on:
TI DSP TMS5541 – each core at 133 MHz
Interfaces
Telephony Interface
1, 2, 4, 8 or 16 E1/T1/J1 Balanced 120/100 ohm, or 75 ohm using a BNC
to RJ-45 dual E1/T1 G.703 Balun adapter. The following Balun adaptors
were tested and certified by AudioCodes:
Manufacture Name: AC&E (Part Number: B04040072)
Manufacture Name: RIT (Part Number: R3712271)
Network Interface
Two 10/100 Base-TX, half or full duplex with auto-negotiation
RS-232 Interface
RS-232 Terminal Interface. DB-9 connector on rear panel (available only
on the 1-, 2-, and 4-span configurations).
PCI Bus
33 MHz, 32 bit, slave mode (PICMG 2.0 revision 2.1)
LED Indicators
LED Indications on Front
Panel
Power, ACT/Fail, T1/E1 status, LAN status, Swap ready indication
Connectors & Switches
Rear Panel
Trunks
1 to 8 and 9 to 16
Two 50-pin female Telco connectors (DDK57AE-40500-21D) or 8 RJ-48c
connectors for trunks 1 to 8 only
Ethernet 1 and 2
Two 10/100 Base-TX, RJ-45 shielded connectors
