<ESP (AES-GCM)>
AES-GCM is used as the ESP algorithm, and authentication and encryption are
both performed.
<AH (SHA1)>
Authentication is performed, but data is not encrypted. SHA1 is used as the
algorithm.
3
Press <OK> <OK>.
8
Enable the registered policies and check the order of priority.
● Select the registered policies from the list, and press <Policy On/Off> to turn them <On>.
● Policies are applied in the order that they are listed, starting at the top. If you want to change the order of
priority, select a policy in the list and press <Raise Priority> or <Lower Priority>.
● If you do not want to send or receive packets that do not correspond to the policies, select <Reject> for
<Receive Non-Policy Packets>.
9
Press <OK>.
10
Press <Apply Set. Changes> <Yes>.
Managing IPSec policies
You can edit policies on the screen displayed in step 3.
● To edit the details of a policy, select the policy in the list and press <Edit>.
● To disable a policy, select the policy in the list and press <Policy On/Off>.
● To delete a policy, select the policy in the list and press <Delete>
<Yes>.
Managing the Machine
612

Canon imagerunner advance C5550i Specifications

General

Type	Color Laser Multifunction Printer
Print Resolution	1200 x 1200 dpi
Scan Resolution	Up to 600 x 600 dpi
Paper Capacity	Standard: 1, 200 sheets; Maximum: 6, 350 sheets
Hard Disk Drive	250 GB
Duplex Printing	Yes
Operating System Compatibility	Windows, Mac OS, Linux
Functions	Print, Copy, Scan
Print Speed	Up to 50 ppm
Copy Speed	Up to 50 ppm (Letter)
Connectivity	USB, Ethernet, Wi-Fi
Display	10.1-inch TFT LCD WSVGA Color Touch Panel
Warm-up Time	Approximately 30 seconds
Memory	4 GB RAM
Fax Resolution	Up to 400 x 400 dpi
Dimensions	620 mm x 742 mm x 932 mm (W x D x H)
