E1 Series Servo Drive User Manual Software Settings And Trial Operation

HIWIN MIKROSYSTEM CORP. 7-3

MD09UE01-1910

7.2 Software installation and connection

Figure7.2.1

Step 1:

Download the setup file of Thunder from

the

official website of HIWIN

Mikrosystem. Correctly install Thunder

into PC.

Step 2:

Connect the servo drive and PC by mini

USB cable. Then open Thunder.exe.

Step 3:

Select the servo drive and click on

Connect button.

Step 4:

The figure on the right is the main screen

of Thunder. Control mode, servo drive

information, firmware version and motor

type are shown in the left column.
