E1 Series Servo Drive User Manual Troubleshooting And Maintenance
13-4 HIWIN MIKROSYSTEM CORP.
13.2 Alarm
13.2.1 Alarm list
The alarms of the servo drive are listed in table 13.2.1.1. If an alarm occurs, perform troubleshooting by
referring to the alarm contents. Alarm type is used to distinguish the stopping method of motor when an
alarm occurs. The stopping method varies with different alarm types. For more information of the stopping
method of motor, please refer to section 6.9.2. To check if an alarm can be cleared by alarm reset input
(ALM-RST) signal, please refer to Alarm Reset column of table 13.2.1.1.
Table13.2.1.1 Alarm list
Alarm Name Alarm Contents
AL.024 System alarm 1
An error occurs in the internal program of the
servo drive.
Gr.A No
AL.025 System alarm 2
An error occurs in the internal program of the
servo drive.
Gr.A No
AL.030 Main circuit malfunction An error occurs in the main circuit. Gr.A Yes
AL.040 Parameter setting error
The parameter setting exceeds the allowable
setting range.
Gr.A No
AL.070 Motor change detected The motor has been changed. Gr.A No
AL.0b0 Invalid servo on command
After the servo drive is turned on, the motor is
enabled by external enabling method or other
enabling method (Thunder or
Gr.A Yes
AL.100 Overcurrent detected
Power transistor overcurrent or heat sink
overheating
Gr.A Yes
AL.320 Regenerative energy overflow Excessive regenerative energy Gr.B Yes
AL.400 Overvoltage The DC voltage of the main circuit is too high. Gr.A Yes
AL.410 Undervoltage The DC voltage of the main circuit is too low. Gr.B Yes
AL.510 Overspeed
The motor velocity exceeds the maximum
velocity.
Gr.A Yes
AL.511 Encoder pulse output overspeed
The maximum bandwidth for encoder pulse
output (18 M/s) is exceeded.
Gr.A Yes
AL.710
Overload (instantaneous maximum
load)
The motor has been operated with torque
exceeding its rated value for a few seconds.
Gr.B Yes
AL.720 Overload (continuous maximum load)
The motor has been continuously operated
with torque exceeding its rated value.
Gr.B Yes
AL.7A2 Power board temperature error The power circuit board overheats. Gr.B No
Encoder data backup error
An error occurs in the encoder backup data.
AL.810 Encoder battery undervoltage
The battery of the absolute encoder is
abnormal.
Gr.A No
AL.820 Encoder communication error Encoder communication error Gr.A No
AL.830 Encoder data error Encoder data reading error Gr.A No
AL.840 Encoder communication crc error Encoder communication interference Gr.A No
AL.850 Encoder counting error Encoder counting error Gr.A No
