E1 Series Servo Drive User Manual Appendix
16-8 HIWIN MIKROSYSTEM CORP.
MD09UE01-1910
16.1.5 Control signal cable
Table16.1.5.1
Name
HIWIN Part
Number
Description
Servo drive
pulse cable
(Standard 50
pins)
HE00EJ6DA300
Connect servo drive (standard) to controller via CN6 to receive or send
pulse command, voltage command, I/O signal, analog monitoring output
signal, encoder output signal, etc. The cable (3 m) is with open ends.
Note:
For other cable lengths, please contact local distributor.
Table 16.1.5.2 Wire color table (standard servo drive)
Pin
Wire Color
Pin
Wire Color
1
Brown
26
Light Green/Black
2
Brown/White
27
Light Green/Yellow
3
Red
28
Light Green/Green
4 Red/Black 29 Blue
5
Red/Blue
30
Blue/White
6
Red/White
31
Light Blue
7
Orange
32
Light Blue/Black
8
Orange/Black
33
Light Blue/Red
9
Pink
34
Light Blue/Yellow
10
Pink/Red
35
Light Blue/Green
11
Pink/Blue
36
Purple
12
Pink/Black
37
Purple/White
13
Pink/Yellow
38
Gray
14
Yellow
39
Gray/Black
15
Yellow/Black
40
Light Blue/Blue
16
Yellow/Red
41
Gray/Red
17
Yellow/Blue
42
Gray/Blue
18
Green
43
Gray/Yellow
19
Pink/White
44
White
20
Green/Black
45
White/Black
21 Green/Blue 46 White/Red
22
Light Green/Red
47
White/Blue
23
Green/White
48
White/Yellow
24
Light Green/Blue
49
White/Green
25
Light Green
50
Gray/Green
Shield
Case
