Hiwin E1 Series User Manual

E1 Series Servo Drive User Manual Specification
HIWIN MIKROSYSTEM CORP. 4-9
MD09UE01-1910
4.3 Basic specification
Table4.3.1 Basic specification
Rated Output 400 W 1 KW 2 KW
Input
Power
Rated Voltage (Line to line)
AC 200 Vrms~AC 240 Vrms, 50~60 Hz
Phase Voltage of Main Power
(Line to line)
1 Ø/AC 200 Vrms~AC 240 Vrms
3 Ø/AC 200 Vrms~AC 240 Vrms
3 Ø/AC 200
Vrms~AC 240 Vrms
Current (Arms)
2.9
6.5
11.3
Control Power 1 Ø, AC 90 V~AC 240 V, 50~60 Hz
Inrush Current of Main Power
(Arms)
14.2 23.4 23.4
Inrush Current of Control Power
(Arms)
17.7 17.7 17.7
Output
Power
Phase Voltage
3 Ø/AC 240 Vrms
Rated Power (W)
400
1 K
2 K
Peak Current (Arms) 10 23.3 42
Rated Current (Arms)
2.5
5.6
12
Frame
B
C
D
Cooling Method Fan cooling
Control Method
IGBT PWM space vector control
PWM Modulation Frequency
16 KHz
8 KHz
Applicable Motor
AC/DM/LM (Depending on encoder type, Excellent Smart Cube
(ESC) may be required.)
STAT LED Indicator
 Blinking red: Error
 Blinking green: Ready
 Green: Enabled
 There is no STAT LED indicator on Fieldbus model.
CHARGE LED Indicator

Red: The control power is supplied.
 No light: The control power is not supplied.
Built-in Regenerative Resistor -
40 Ohm
/40 W
12 Ohm
/60 W
Dynamic Brake

Built-in dynamic brake
 Delay time of relay: 20 ms
Built-in Resistor for Dynamic Brake
-
10 Ohm
Analog Output
 Channel: 2
 Resolution: 12 bit
 Output voltage range: ±10 V
 Accuracy: ±2%
 Maximum output current: ± 10 mA
