E1 Series Servo Drive User Manual Appendix
HIWIN MIKROSYSTEM CORP. 16-11
MD09UE01-1910
16.2 Accessories
16.2.1 Accessory kit
The accessory kit is included when the servo drive is shipped out.
Table16.2.1.1
Name
HIWIN Part
Number
Description Qty.
ED1 CK1
accessory kit
(Standard)
051800200158
CN1: AC main power input terminal, control power input
terminal, terminal for regenerative resistor and terminal for DC
reactor (11 pins, TE 1-2229794-1-PT1)
1
CN2: Motor power connector (3 pins, TE 3-2229794-1) 1
CN4: STO connector (TE 1971153-1) 1
CN6: Control signal connector (50 pins welded type EUMAX
XDR-10350AS)
1
Headers and wire housings for CN1 and CN2 connectors (TE
1981045-1)
2
ED1 CK2
accessory kit
(Fieldbus)
051800200159
CN1: AC main power input terminal, control power input
terminal, terminal for regenerative resistor and terminal for DC
reactor (11 pins, TE 1-2229794-1-PT1)
1
CN2: Motor power connector (3 pins, TE 3-2229794-1) 1
CN4: STO connector (TE 1971153-1) 1
CN6: Control signal connector (36 pins welded type EUMAX
XDR-10336AS)
1
Headers and wire housings for CN1 and CN2 connectors (TE
1981045-1)
2
16.2.2 Power supply filter
Table16.2.2.1
Name
HIWIN Part
Number
Description
Filter
(Single-phase
power supply)
051800200044
Single-phase filter FN2090-10-06, for 400 W ~ 1 KW models
(rated current: 10A, leakage current: 0.67 mA)
Filter
(Three-phase
power supply)
051800200071
Three-phase filter FN3025HL-20-71, for 1 KW or 2 KW model
(rated current: 20 A, leakage current: 0.4 mA)
