E1 Series Servo Drive User Manual Parameters
15-4 HIWIN MIKROSYSTEM CORP.
MD09UE01-1910
Pt No.
Pt001
Size 2
Setting
Range
0000~0042 Default 0030
Name
Application function
selection 1
Unit -
Applicable
Motor
All
Effective
After power on
Category
Setup
Reference
-
Description
t.X
Stopping method for servo off and Gr.A alarm Reference
0
Use dynamic brake to stop the motor. The dynamic brake remains activated
after the motor stops.
-
1
Use dynamic brake to stop the motor. The dynamic brake is deactivated
after the motor stops.
-
2 Do not use dynamic brake. Let the motor run freely until it stops. -
t.X
Stopping method for overtravel (OT) Reference
0
Use dynamic brake to stop the motor or let the motor run freely until it stops.
The stopping method is the same as Pt001 = t.

X.
-
1
Use the setting value of Pt406 as the maximum torque to decelerate the
motor to a stop. The motor stops in zero clamp state.
2
Use the setting value of Pt406 as the maximum torque to decelerate the
motor to a stop. The motor runs freely afterwards.
3
Use the deceleration time set in Pt30A to decelerate the motor to a stop.
The motor stops in zero clamp state.
4
Use the deceleration time set in Pt30A to decelerate the motor to a stop.
The motor runs freely afterwards.
t.X Reserved (Do not modify.)
t.X Reserved (Do not modify.)
