Suzuki GSF650 Service Manual

Engine Lubrication System: 1E-2
Schematic and Routing Diagram
Engine Lubrication System Chart Diagram
B817H21502001
INTAKE CAMSHAFT
CAM CHAIN
TENSION ADJUSTER
#1 PISTON COOLING
OIL JET
#1 PISTON AND
CYLINDER WALL
#1 CRANK PIN
BEARING
CRANKSHAFT
JOURNAL BEARING
STARTER DRIVEN
GEAR BEARING
CRANKSHAFT
JOURNAL BEARING
CRANKSHAFT
JOURNAL BEARING
CRANKSHAFT
JOURNAL BEARING
CRANKSHAFT
JOURNAL BEARING
CRANKSHAFT
JOURNAL BEARING
OIL PRESSURE
SWITCH
#2 CRANK PIN
BEARING
OIL PUMP
OIL STRAINER
OIL PRESSUER
REGULATOR
CLUTCH PUSH PIECE AND
PRIMARY DRIVEN GEAR BEARING
CLUTCH PLATES
#3 CRANK PIN
BEARING
#4 CRANK PIN
BEARING
#2 PISTON AND
CYLINDER WALL
#3 PISTON AND
CYLINDER WALL
#4 PISTON AND
CYLINDER WALL
#2 PISTON COOLING
OIL JET
#3 PISTON COOLING
OIL JET
#4 PISTON COOLING
OIL JET
EXHAUST CAMSHAFT
CAMSHAFT JOURNALS,
CAMFACES, TAPPETS
CAMSHAFT JOURNALS,
CAMFACES, TAPPETS
MAIN-GALLERY
OIL PAN
EXHAUST CAMSHAFT
JOURNAL HOLDER (B)
OIL FILTER
INTAKE CAMSHAFT
JOURNAL HOLDER (D)
COUNTERSHAFT
AND GEARS
DRIVESHAFT
AND GEARS
OIL JET (#18)
OIL JET (#14)
OIL JET (#8)
CAMSHAFT RIB AND
CAM DRIVE CHAIN
INTAKE CAMSHAFT
JOURNAL HOLDERS (C)
EXHAUST CAMSHAFT
JOURNAL HOLDERS (A)
GENERATOR COVER
GENERATOR COIL
OIL GALLERY JET
I717H1150001-04

Suzuki GSF650 Specifications

General

Displacement	656 cc
Bore x Stroke	65.5 mm x 48.7 mm
Compression Ratio	11.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Starter	Electric
Transmission	6-speed, constant mesh
Final Drive	Chain
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Tire	120/70ZR17M/C (58W), tubeless
Rear Tire	160/60ZR17M/C (69W), tubeless
Overall Length	2, 130 mm
Rear Brakes	Disc brake
Fuel Tank Capacity	19.0 L
Wheelbase	1, 470 mm
Seat Height	790 mm
Ground Clearance	135 mm
Engine Type	4-stroke, liquid-cooled, DOHC, 4-cylinder
