Suzuki GSF650 Service Manual

ABS: 4E-68
DTC “61” (C1661): ABS Solenoid Malfunction
B817H24504024
Troubleshooting
Possible Cause
Faulty solenoid valve or relay
Step Action Yes No
1 1) Turn the ignition switch OFF.
2) Remove the seat. Refer to “Exterior Parts Removal and
Installation (GSF650/S/A/SAK7) in Section 9D
(Page 9D-6)”.
3) Inspect the ABS solenoid valve fuse.
CAUTION
!
If a fuse is blown, find the cause of the problem
and correct it before replacing the fuse.
ABS solenoid valve fuse
15 A
Is the ABS solenoid valve fuse OK?
Go to Step 2. Replace the ABS
solenoid valve fuse.
I717H2450023-01

Suzuki GSF650 Specifications

General

Displacement	656 cc
Bore x Stroke	65.5 mm x 48.7 mm
Compression Ratio	11.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Starter	Electric
Transmission	6-speed, constant mesh
Final Drive	Chain
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Tire	120/70ZR17M/C (58W), tubeless
Rear Tire	160/60ZR17M/C (69W), tubeless
Overall Length	2, 130 mm
Rear Brakes	Disc brake
Fuel Tank Capacity	19.0 L
Wheelbase	1, 470 mm
Seat Height	790 mm
Ground Clearance	135 mm
Engine Type	4-stroke, liquid-cooled, DOHC, 4-cylinder
