Suzuki GSF650 Service Manual

ABS: 4E-8
ABS Unit Diagram
B817H24502002
Refer to “Wire Color Symbols in Section 0A (Page 0A-5)”.
Battery
Ignition
Ignition
ABS
Brake light switch
Brake light switch
ABS indicator light
Solenoid Battery (+)
Fail safe relay
Motor relay
Ground
Front wheel speed sensor
Rear wheel speed sensor
Mode select coupler
ABS control unit
M
Ground
24
25
2
2
3
3
12
12
12
13
13
13
18
18
18
10
10
10
4
4
11
11
21
16
16
16
8
9
2
3
4
10
21
12
13
16
18
24
8
9
25
Motor
ground
SDS
O/Y Br W/B
R/Bl R/B
B/W B/W
W/YB/YB/R
OGr
W/R
ABS motor fuse (20 A)
ABS valve fuse (15 A)
“A”
“B” “C”
“D”
“E”
“F”
“G”
I718H1450021-04
“A”: Rear brake solenoid OUT “C”: Front brake solenoid OUT “E”: Fail safe (+) B “G”: Motor (+) B
“B”: Rear brake solenoid IN “D”: Front brake solenoid IN “F”: Motor relay (+) B

Suzuki GSF650 Specifications

General

Displacement	656 cc
Bore x Stroke	65.5 mm x 48.7 mm
Compression Ratio	11.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Starter	Electric
Transmission	6-speed, constant mesh
Final Drive	Chain
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Tire	120/70ZR17M/C (58W), tubeless
Rear Tire	160/60ZR17M/C (69W), tubeless
Overall Length	2, 130 mm
Rear Brakes	Disc brake
Fuel Tank Capacity	19.0 L
Wheelbase	1, 470 mm
Seat Height	790 mm
Ground Clearance	135 mm
Engine Type	4-stroke, liquid-cooled, DOHC, 4-cylinder
