1A-21 Engine General Information and Diagnosis:
DTC Table
B817H21104006
In the LCD (DISPLAY) panel, the malfunction code is indicated from small code to large code.
Code Malfunction Part Remarks
C00 None No defective part
C12 (P0335)
)(Page 1A-27)
Crankshaft position sensor (CKPS) Pick-up coil signal, signal generator
C13 (P0105-H/L)
)(Page 1A-30)
Intake air pressure sensor #1 (IAPS)
C14 (P0120-H/L)
)(Page 1A-39)
Throttle position sensor (TPS)
C15 (P0115-H/L)
)(Page 1A-47)
Engine coolant temperature sensor (ECTS)
C17 (P1750-H/L)
)(Page 1A-54)
Intake air pressure sensor #2 (IAPS)
C21 (P0110-H/L)
)(Page 1A-62)
Intake air temperature sensor (IATS)
C23 (P1651-H/L)
)(Page 1A-69)
Tip-over sensor (TOS)
C24 (P0351)
)(Page 1A-75)
Ignition signal #1 (IG coil #1) For #1 cylinder
C25 (P0352)
)(Page 1A-75)
Ignition signal #2 (IG coil #2) For #2 cylinder
C26 (P0353)
)(Page 1A-75)
Ignition signal #3 (IG coil #3) For #3 cylinder
C27 (P0354)
)(Page 1A-75)
Ignition signal #4 (IG coil #4) For #4 cylinder
C28 (P1655)
)(Page 1A-75)
Secondary throttle valve actuator (STVA)
C29 (P1654-H/L)
)(Page 1A-75)
Secondary throttle position sensor (STPS)
C31 (P0705)
)(Page 1A-87)
Gear position signal (GP switch)
C32 (P0201)
)(Page 1A-89)
Injector signal #1 (FI #1) For #1 cylinder
C33 (P0202)
)(Page 1A-89)
Injector signal #2 (FI #2) For #2 cylinder
C34 (P0203)
)(Page 1A-89)
Injector signal #3 (FI #3) For #3 cylinder
C35 (P0204)
)(Page 1A-89)
Injector signal #4 (FI #4) For #4 cylinder
C40 (P0505/
P0506/P0507)
)(Page 1A-93)
Idle speed control valve (ISC valve)
C41 (P0230-H/L,
P2505)
)(Page 1A-99)
Fuel pump control system (FP control system),
ECM/PCM power input signal
Fuel pump, Fuel pump relay
C42 (P1650)
)(Page 1A-104)
Ignition switch signal (IG switch signal) Anti-theft
C44 (P0130/
P0135)
)(Page 1A-104)
Heated oxygen sensor (HO2S)
C49 (P1656)
)(Page 1A-110)
PAIR control solenoid valve
C60 (P0480)
)(Page 1A-114)
Cooling fan control system Cooling fan relay
