2C-13 Rear Suspension:
Specifications
Service Data
B817H22307001
Unit: mm (in)
Tightening Torque Specifications
B817H22307002
NOTE
The specified tightening torque is described in the following.
“Rear Suspension Components (Page 2C-1)”
“Rear Suspension Assembly Construction (Page 2C-2)”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Tightening Torque List in Section 0C
(Page 0C-7)”.
Special Tools and Equipment
Recommended Service Material
B817H22308001
NOTE
Required service material is also described in the following.
“Rear Suspension Components (Page 2C-1)”
“Rear Suspension Assembly Construction (Page 2C-2)”
Item Standard Limit
Rear shock absorber spring
adjuster
3rd position —
Rear shock absorber damping
force adjuster
Rebound 1-1/4 turns out from stiffest position —
Rear wheel travel 128 (5.0) —
Swingarm pivot shaft runout — 0.3 (0.01)
Fastening part
Tightening torque
Note
N⋅m kgf-m lbf-ft
Rear shock absorber mounting nut
50 5.0 36.0
)(Page 2C-3) /
)(Page 2C-6) /
)(Page 2C-10)
Cushion lever mounting nut
78 7.8 56.5
)(Page 2C-4) /
)(Page 2C-6) /
)(Page 2C-10)
Front footrest bracket mounting bolts
35 3.5 25.5
)(Page 2C-4) /
)(Page 2C-6)
Rear brake master cylinder 23 2.3 16.5 )(Page 2C-4)
Cushion rod mounting nut
78 7.8 56.5
)(Page 2C-6) /
)(Page 2C-10)
Rear brake master cylinder mounting bolts 23 2.3 16.5 )(Page 2C-6)
Swingarm pivot nut 100 10.0 72.5 )(Page 2C-9)
Material SUZUKI recommended product or Specification Note
Grease SUZUKI SUPER GREASE A or
equivalent
P/No.: 99000–25010 )(Page 2C-8) / )(Page 2C-
12)
