Suzuki GSF650 Service Manual

9C-17 Combination Meter / Fuel Meter / Horn:
Specifications
Service Data (GSF650/S/A/SAK7)
B817H29307001
Wattage
Unit: W
Service Data (GSX650FK8)
B817H29307003
Wattage
Unit: W
Tightening Torque Specifications
B817H29307004
Reference:
For the tightening torque of fastener not specified in this section, refer to “Tightening Torque List in Section 0C
(Page 0C-7)”.
Special Tools and Equipment
Special Tool
B817H29308001
Item
Specification
GSF650/A GSF650S/SA
Speedometer light LED ←
Tachometer light LED ←
Turn signal indicator light LED x 2 ←
High beam indicator light LED ←
Neutral position indicator light LED ←
Oil pressure indicator light LED ←
Coolant temperature indicator light LED ←
FI indicator light LED ←
Item Specification
Speedometer light LED
Tachometer light LED
Turn signal indicator light LED x 2
High beam indicator light LED
Neutral position indicator light LED
Oil pressure/Engine coolant temperature indicator light LED
FI indicator light LED
Engine RPM indicator light LED
Fastening part
Tightening torque
Note
N⋅mkgf-mlbf-ft
Speed sensor bolt 6.5 0.65 4.7 )(Page 9C-10)
09900–25008
Multi-circuit tester set
)(Page 9C-9) / )(Page 9C-
10) / )(Page 9C-11) /
)(Page 9C-12)

Suzuki GSF650 Specifications

General

Displacement	656 cc
Bore x Stroke	65.5 mm x 48.7 mm
Compression Ratio	11.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Starter	Electric
Transmission	6-speed, constant mesh
Final Drive	Chain
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Tire	120/70ZR17M/C (58W), tubeless
Rear Tire	160/60ZR17M/C (69W), tubeless
Overall Length	2, 130 mm
Rear Brakes	Disc brake
Fuel Tank Capacity	19.0 L
Wheelbase	1, 470 mm
Seat Height	790 mm
Ground Clearance	135 mm
Engine Type	4-stroke, liquid-cooled, DOHC, 4-cylinder
