9D-14 Exterior Parts:
Intake Net Cover Construction Attachment (GSX650FK8)
B817H29406017
Exterior Parts Removal and Installation
(GSX650FK8)
B817H29406010
Under Cowling
Refer to “Exterior Parts Removal and Installation
(GSF650/S/A/SAK7) (Page 9D-6)”.
Removal
1) Remove the fasteners (1).
2) Disconnect the turn signal light couplers (2), left and
right.
1
I817H2940020-01
1. Cover cushion
1
I817H2940001-01
2
2
I817H2940002-01
